Turbo Electronic Actuator SA1150-56-24V- 3791993 for Cummins ISX
Product:Turbo Actuator
Part Number: P-3791993; HW-3787596
Application: Cummins ISX
Condition: New
Package: Neutral Carton
Delivery time: 30 Working Days After Payment Confirmed
Actuator part No. | 3791993 |
Voltage | 24V2 |
Software Version | 2.28.2 |
Connector Type | D type |
Harness Length | 640 mm |
Coolant | 3inM10 * 1.0; 7out M12 * 1.5 |
Communication | CAN J1939 |
Actuator Size | L*W*H=211*87*115.2mm |
Notes:
To ensure correct actuator selection and installation:
- We strongly recommend that the actuator be installed by a professional using the necessary scanner or diagnostic equipment for proper pre-alignment with the turbocharger.
- If you are unable to identify your turbocharger actuator manufacturer or part number, SACER technical staff will assist you with identification.
- You may send us a reference photo of your actuator for confirmation before ordering.
Ref. NO.
3791993 3787596 3787560
Turbocharger NO.
3775687 3775690 3792580 5350515 5501271 5350511 3795124 3779565 3768190 3796105 5354741 3791151 3796100
Application
Cummins ISX
SACER SA1150 smart electronic actuator is designed for VGT (Variable Geometry Turbocharger) systems used in medium-duty and heavy-duty diesel engines. It is widely applied in turbocharger control to improve engine efficiency, reduce emissions, and meet current and future exhaust emission standards.
This actuator precisely controls the turbocharger vane position, ensuring real-time coordination between the engine combustion process and turbocharging system. It helps optimize air intake, improve fuel economy, and reduce exhaust pollution in demanding HDV (Heavy Duty Vehicle) applications.
Key features include:
- High-precision positioning for VGT turbocharger control
- Faster response for improved engine performance and emission control
- Supports fuel efficiency optimization and lower emissions
- Designed for ISO9001 / IATF16949 compliant manufacturing standards
- Wide operating temperature range: -40°C to 125°C
- Flexible adjustment angle up to 120° for heavy-duty applications
SACER SA1150 actuator is suitable for a wide range of diesel engine turbocharger systems where stable performance, durability, and emission compliance are required.
R&D Innovation Center
Advanced engineering team with 15+ years of turbo system expertise, utilizing CAD/CAE simulation and rapid prototyping for continuous product innovation.
Comprehensive Testing Lab
Full-spectrum validation including durability cycles, thermal shock (-40°C to +150°C), vibration resistance, and EMC compliance testing.
Quality Management System
IATF 16949:2016 & ISO 9001:2015 certified production with 100% incoming inspection, in-process monitoring, and final performance verification.
From application evaluation to global delivery, SACER provides reliable actuator solutions and services for OEM and aftermarket customers worldwide.
Product Identification & Model Matching
Based on the product information provided by the customer—such as OE number, turbocharger model, or product photos—we provide actuator model identification and matching services to help quickly find the correct replacement.
Flexible Customization & Quality Assurance
We provide flexible customization options supported by strict quality control and validation processes to ensure stable and reliable product performance.
Global Delivery & Technical Support
Our global logistics network and responsive technical support ensure efficient product delivery and long-term cooperation.
SACER provides full warranty and after-sales support. Download the official document below for details.
