Turbo Electronic Actuator SA1150-53-24V- 3787560 for Cummins Engine ISX
Product:Turbo Actuator
Part Number: P-3787560; HW-3787596
Version/Model: 24V-V2 PCBA
Application: Cummins Engine ISX
Condition: New
Package: Neutral Carton
Delivery time: 30 Working Days After Payment Confirmed
Actuator part No. | 3787560 |
Voltage | 24V2 |
Software Version | 2.28.2 |
Connector Type | D type |
Harness Length | 640mm |
Coolant | 3inM10*1.0; 4&5outM10*1.0 |
Communication | CAN J1939 |
Actuator Size | L*W*H=211*87*115.2mm |
Notes:
To ensure correct actuator selection and installation:
- We strongly recommend that the actuator be installed by a professional using the necessary scanner or diagnostic equipment for proper pre-alignment with the turbocharger.
- If you are unable to identify your turbocharger actuator manufacturer or part number, SACER technical staff will assist you with identification.
- You may send us a reference photo of your actuator for confirmation before ordering.
Ref. NO.
2835866 2835945 2837216 2840222 2840222RX 3787560 3787596 3787562 3787562RX 3787564 3787566 3787597 4032766 4034117 4034125 4034125H 4034125HX 4034128 4034128RX 4034288 4034288H 4034288HX 4034288NX 4034288RX 4034401 6379045 6379342RX 6379347 6379347H 6379347HX 4034126 4034288 4034288H
Turbocharger NO.
2836893 2836894 2836894NX 2836894RX 2837608 2840878 2843262 2843263 2843263NX 2843263RX 3773403 3773407 3773420 3773420NX 3773420RX 3773423 3793693 3793769 3795538 3795545 3795558 4352382 4352382RX 5501565 5501565H 5501565NX 5501565RX 5502827 3793765 3793764 2840862 3768686 3793765 3794574 4352378 2840860 3768650 3793705 3795911 3773526 3795893 5456049 3768162 3773513 3795880 3795877
Application
Cummins Engine ISX
SACER SA1150 smart electronic actuator is designed for VGT (Variable Geometry Turbocharger) systems used in medium-duty and heavy-duty diesel engines. It is widely applied in turbocharger control to improve engine efficiency, reduce emissions, and meet current and future exhaust emission standards.
This actuator precisely controls the turbocharger vane position, ensuring real-time coordination between the engine combustion process and turbocharging system. It helps optimize air intake, improve fuel economy, and reduce exhaust pollution in demanding HDV (Heavy Duty Vehicle) applications.
Key features include:
- High-precision positioning for VGT turbocharger control
- Faster response for improved engine performance and emission control
- Supports fuel efficiency optimization and lower emissions
- Designed for ISO9001 / IATF16949 compliant manufacturing standards
- Wide operating temperature range: -40°C to 125°C
- Flexible adjustment angle up to 120° for heavy-duty applications
SACER SA1150 actuator is suitable for a wide range of diesel engine turbocharger systems where stable performance, durability, and emission compliance are required.
