Turbo Actuator SA1170-9-12V-835556-0248 for Ford EcoBlue 2.0L Transit Custom 2022-2023
Product:Turbo Actuator
Part Number: 835556-0248
Voltage: 12V
Application: Ford EcoBlue 2.0L Transit Custom 2022-2023
Condition: New
Package: Neutral Carton
Delivery time: 30 Working Days After Payment Confirmed
Actuator Part No. | 835556-0248 |
Garrett Actuator No. | 850841-0010 |
Turbocharger Type | Electronic VGT |
Ford OE No. | KK3Q-6K682-BC |
Voltage | 12V |
Notes:
To ensure correct actuator selection and installation:
- We strongly recommend that the actuator be installed by a professional using the necessary scanner or diagnostic equipment for proper pre-alignment with the turbocharger.
- If you are unable to identify your turbocharger actuator manufacturer or part number, SACER technical staff will assist you with identification.
- You may send us a reference photo of your actuator for confirmation before ordering.
OEM NO. | 835556-0248 |
Engine | Ford EcoBlue 2.0L |
Vehicle/Year | Ford Transit Custom 2022 Ford Transit Custom 2023 |
Refer No. | / |
Turbocharger NO. | 850841-0010 |
SACER SA1170 smart electronic actuator is designed for electronically controlled turbocharger systems used in small-displacement passenger cars and light-duty diesel engines. It is widely applied to e-WGT (Electronic Wastegate Turbocharger) and e-VG/VNT (Variable Geometry Turbocharger) systems to optimize turbocharger performance, improve engine efficiency, and support modern exhaust emission requirements.
Key features include:
- High-precision position control for e-WGT and e-VG/VNT turbocharger systems
- Intelligent rotating position feedback for accurate actuator control
- PWM interface for responsive electronic turbocharger regulation
- Precise lever positioning with angle tolerance of up to ±1.5°
- Wide operating voltage range: 10.5–16 V DC, nominal 14 V
- Wide operating temperature range: -40°C to +125°C
SACER SA1170 actuator is suitable for a wide range of electronically controlled turbocharger applications, particularly small-displacement passenger cars and light-duty diesel engines, where precise boost control, fast response, durability, and emission performance are required.
R&D Innovation Center
Advanced engineering team with 15+ years of turbo system expertise, utilizing CAD/CAE simulation and rapid prototyping for continuous product innovation.
Comprehensive Testing Lab
Full-spectrum validation including durability cycles, thermal shock (-40°C to +150°C), vibration resistance, and EMC compliance testing.
Quality Management System
IATF 16949:2016 & ISO 9001:2015 certified production with 100% incoming inspection, in-process monitoring, and final performance verification.
From application evaluation to global delivery, SACER provides reliable actuator solutions and services for OEM and aftermarket customers worldwide.
Product Identification & Model Matching
Based on the product information provided by the customer—such as OE number, turbocharger model, or product photos—we provide actuator model identification and matching services to help quickly find the correct replacement.
Flexible Customization & Quality Assurance
We provide flexible customization options supported by strict quality control and validation processes to ensure stable and reliable product performance.
Global Delivery & Technical Support
Our global logistics network and responsive technical support ensure efficient product delivery and long-term cooperation.
SACER provides full warranty and after-sales support. Download the official document below for details.
