SA1160-UTA-G030-H16 Electronic Turbo Actuator Repair For Hella 6NW010099-16 For Garrett 797862-0030

SKU
SA1160-UTA-G030-H16

Secured and trusted checkout with

TYPICAL APPLICATIONS

SACER SA1160-UTA-G030-H16 Smart Electronic Actuators are typically used for Garrett VNT turbo (applications such as passenger car / LDV duty diesel engines to help provide optimum performance and enable compliance with current and future exhaust emissions standards.

G NO./6NW NO.

6NW010099-16

Garrett Turbo NO.

797862-0030

Application

SYMC D22DTF&DTR EU6 CONCEPT

Connector position

middle

Features

Lever angle tolerance ≤ +/-1.5degree
Lever clearance tolerance ≤+/- 1.75 degree
Lever move torque ≥ 2.5 Nm
High quality laser welding
Power supply : DC 14V (Range: 10.5V to 16V)
Temp. range(Operation): -40℃ to +125℃
Temp. range(Storage): -40℃ to +150℃

Quality control

Full function OQC test and confirm for every unit.

2 years Full European Warranty Finish full function test, temperature test, endurance test, drop test, vibration test, salt spray test, destructive test, EMC test.
